Specifications
Range
Resolution
Accuracy
DC Voltage
400mV/4V/40V/400V
600V
600V
0.1mV/1mV/10mV/0.1V
1V
1V
±(0.5%+2)
±(0.8%+2)
±(0.8%+2)
AC Voltage
400mV
4V/40V/400V
600V
4V/40V/400V
600V
0.1mV
1mV/10mV/0.1V
1V
1mV/10mV/0.1V
1V
±(2.0%+3)
±(0.8%+3)
±(1.0%+3)
±(0.8%+3)
±(1.0%+3)
DC Current
400μA/4000μA/40mA/400mA
4A/10A
4A/10A
0.1μA/1μA/10μA/0.1mA
1mA/10mA
1mA/10mA
±(0.8%+2)
±(1.2%+2)
±(1.2%+2)
AC Current
400μA/4000μA/40mA/400mA
4A/10A
4A/10A
0.1μA/1μA/10μA/0.1mA
1mA/10mA
1mA/10mA
±(1.5%+2)
±(2.0%+2)
±(2.0%+2)
Resistance
400Ω/4kΩ/40kΩ/400kΩ/4MΩ
40MΩ
40MΩ
0.1Ω/1Ω/10Ω/0.1kΩ/1kΩ
10kΩ
10kΩ
±(1.0%+3)
±(1.2%+15)
±(1.2%+15)
Capacitance
40nF/400nF/4μF
40μF/400μF/4000μF
40μF/400μF/4000μF
10pF/0.1nF/1nF
40nF/0.1μF/1μF
40nF/0.1μF/1μF
±(3.0%+5)
±(3.0%+5)
±(3.0%+5)
Frequency
10Hz/100Hz/1kHz/10kHz
100kHz/1MHz/10MHz
100kHz/1MHz/10MHz
0.001Hz/0.01Hz/0.1Hz/1Hz
10Hz/0.1kHz/1kHz
10Hz/0.1kHz/1kHz
±(0.5%+2)
±(0.5%+2)
±(0.5%+2)
Duty Cycle
1%~99%
0.1%
±(2.0%+5)
Temperature
-20℃~0℃
1℃~400℃/
401℃~1000℃
--4℉~32℉
33℉~752℉
753℉~1832℉
1℃~400℃/
401℃~1000℃
--4℉~32℉
33℉~752℉
753℉~1832℉
1℃
1℃
1℃
1℉
1℉
1℉
1℃
1℃
1℉
1℉
1℉
±(5.0%+4)
±(1.0%+3)
±(2.0%+2)
±(5.0%+7)
±(2.0%+4)
±(2.0%+4)
±(1.0%+3)
±(2.0%+2)
±(5.0%+7)
±(2.0%+4)
±(2.0%+4)
Features
Display
Counts
4000
Autoranging
Auto & Manual
Yes
APO
Auto Power Off
Yes
REL
Relative Measurment
Yes
Transistor hFE
0~1000
Yes
Diode
Open Voltage
3.0V
Continuity Buzzer
<50±20Ω
Yes
Data Hold
Yes
NCV
Non-Contact Voltage Detector
Yes
MAX / MIN
Yes
LBD
Low Battery Display
Yes
Bar Graph
Yes
Display Backlight
Yes
